CELA DT 100 SERIES
Cela DT 100 Truck
Compact High-Reach.
A remarkable addition to the lineup with a 100 ft working height and a compact footprint. The DT-type boom delivers exceptional outreach, up-and-over and negative reach in a road-legal package.
Overview
An engineering marvel from Cesena, Italy.
The DT Truck 100 mounts on chassis with a low Gross Vehicle Weight of just 6.5 T, setting it apart from the competition. Its unique DT-type boom design enables outstanding outreach, overreach and negative reach for the most challenging worksites.
While basket and hook payloads are slightly lower than the DT Truck 28, the DT Truck 100 more than compensates with its extended working height. It accepts the same accessory range as the rest of the line.
The cabin takes command and the boom is nearly invisible when folded — seamlessly tucked behind the driver's cab for easy transport.
At a glance
Why operators choose the DT 100 Truck.
- Mounts on 6.5 T GVW chassis
- 100 ft working height — extended reach
- 1440° continuous turret rotation
- Compact folded footprint
Reach & Specifications
Every working envelope, every number.
The double-telescopic boom delivers a 100 ft vertical reach with a true 49 ft horizontal outreach and a 52 ft up-and-over clearance — the largest working envelope in its class.
Working envelope · Cela DT 100 Truck
- Working height
- 100 ft
- Negative reach
- −23 ft
- Up & over
- 52 ft
- Horizontal outreach
- 49 ft
- Platform height
- 92 ft
- Basket capacity
- 225 kg / 496 lb
- Hook capacity
- 260 kg / 573 lb
- Turret rotation
- 1440°
- Basket rotation
- 90° + 90°
- Basket dimensions
- 5.9 × 2.3 × 3.6 ft
- Stabilization
- H + H
- Platform controls
- Electronic
Features
Built for the way you work.
Every detail of the Cela DT 100 Truck is engineered for productivity, safety, and total cost of ownership.
In the field
